A case study using the VIABAHN® Device

Challenge

  • 72-year-old male with thrombosed left arm arteriovenous (AV) graft
  • Graft was initially placed eight years ago followed by multiple interventions
Angiogram



Image: Thrombosed left arm AV graft. 80% stenosis just past venous anastomosis.

Images courtesy of Jason Burgess, M.D. Used with permission.

Procedure

  • A percutaneous thrombectomy was performed with the BOSTON SCIENTIFIC ANGIOJET Thrombectomy System
  • The patient was found to have 80% stenosis just past the venous anastomosis
  • Stenosis at the venous anastomosis was treated with balloon angioplasty with immediate recoil of stenosis
  • A VIABAHN® Device, 7 mm x 5 cm, was then placed across the venous anastomosis
angiogram



Image: Prior to the placement of a VIABAHN® Device, balloon angioplasty was performed to predilate the lesion at the venous anastomosis of the graft.

Images courtesy of Jason Burgess, M.D. Used with permission.

Result

  • Excellent angiographic result
  • Thrill restored to the graft
Angiogram



Image: Post placement of 7 mm x 5 cm VIABAHN® Device

Images courtesy of Jason Burgess, M.D. Used with permission.

Case takeaways

The VIABAHN® Device successfully treated a graft outflow lesion that had failed balloon angioplasty.
