A case study using the VIABAHN® Device



Challenge

  • 77-year-old female with end-stage renal disease on hemodialysis via a right upper extremity axillary artery to axillary vein ePTFE loop graft
  • Presented after unsuccessful attempt at dialysis due to an occluded graft
  • Relevant patient history:
    • Access was created four months prior to presentation
    • Venogram performed two months prior to presentation for pulsatility and recirculation demonstrated venous anastomotic tenosis, for which drug-eluting balloon venoplasty was performed
Angiogram

Image: Balloon angioplasty during clot maceration of a thrombosed upper arm graft reveals tight stricture at the venous anastomosis. The same lesion was previously treated two months prior.

Images courtesy of Thomas Ward, M.D. Used with permission.

Procedure

  • Initial ultrasound images demonstrated the length of the graft to be occluded. Antegrade and retrograde access was obtained.
  • Pharmacological thrombolysis was performed with 4 mg tPA followed by balloon maceration across the length of the graft
  • Contrast was injected via the antegrade sheath, demonstrating persistent moderate stenosis
  • Given short-term recurrence and graft occlusion, an 8 mm x 7.5 cm VIABAHN® Device was deployed to treat the recurrent venous anastomotic stenosis
Angiogram

Image: Persistent stenosis at the venous anastomosis after balloon angioplasty.

Images courtesy of Thomas Ward, M.D. Used with permission.

Result

  • Completion AV graft venogram demonstrated the graft and venous outflow stent to be widely patent
  • A brisk thrill was palpated
  • Patient had successful hemodialysis immediately following the procedure and dialysis access circuit remains patent
Angiogram

Image: Brisk thrill re-established after placement of 8 mm x 7.5 cm VIABAHN® Device.

Images courtesy of Thomas Ward, M.D. Used with permission.

Case Takeaways

  • The VIABAHN® Device remains an excellent option for percutaneous revision of venous anastomotic stenosis in patients with a prosthetic hemodialysis graft
  • In this patient with short-term recurrent stenosis after drug-eluting balloon venoplasty, use of the VIABAHN® Device aided in re-establishing access circuit patency
